The Memory Time Bomb Hiding in Your Kubernetes Cluster

I found a ticking time bomb in my Kubernetes cluster this week.

Not over-provisioned.Not under-provisioned.Just... missing.

I ran Goldilocks on my Kubernetes practice cluster expecting to find the usual CPU waste.

What I found was worse:

3 out of 4 system pods have incomplete or missing memory configuration.

kube-proxy: No memory config at allaws-node: No memory config at allCoreDNS: Has request (70Mi), no limitmetrics-server: Properly configured

Both kube-proxy and aws-node route ALL traffic in my cluster.Both are one memory spike away from OOM kill.Both capable of taking down the entire platform.

And this is the DEFAULT configuration.

I installed Goldilocks last week. Took 5 minutes.

I expected the usual problem: CPU over-provisioning. System pods requesting 100m but using 25m. The 4x waste that exists in every cluster.

Wasteful, but at least safe.

What I found: Missing memory limits everywhere.

Here’s the exact command:

kubectl get pods --all-namespaces -o json | jq ‘.items[] | select(.spec.containers[].resources.requests.memory == null) | .metadata.name’

Output:

kube-proxy-bv6crkube-proxy-l2lkc

Two critical system components with NO memory configuration at all.

CoreDNS wasn’t in this list. Why?

Because it HAS a memory request (70Mi) set by default.

But check the limits:

kubectl get pods -n kube-system -o custom-columns=\NAME:.metadata.name,\QOS:.status.qosClass,\MEM-REQ:.spec.containers[0].resources.requests.memory,\MEM-LIM:.spec.containers[0].resources.limits.memory

Output :

coredns-xxxxx: Burstable, 70Mi,kube-proxy-xxxxx: BestEffort, ,metrics-server-xxxxx: Guaranteed, 200Mi, 200Mi

3 out of 4 system pods are vulnerable.

This isn’t a misconfiguration.This is how Kubernetes ships.

Let me walk through what happens when these missing configs meet a real workload problem.

This is based on how Linux OOM Killer actually works - the mechanics are real, even if I’m using a hypothetical scenario to illustrate.

Scenario: You deploy a workload without memory limits.

Could be anything:

→ Batch job that gets more data than expected

→ An App with a memory leak

→ A background task that spikes every Saturday morning

Normally it uses 2GB. Under load? 8GB.

Your node is running on limited resources. Let’s say 8GB RAM total.

That workload climbs: 500MB → 1GB → 2GB → 4GB → 8GB

No limit = nothing stops it.

Here’s what it evaluates:

Your workload:→ PriorityClass: None (priority 0)→ QoS: BestEffort (no requests/limits)→ Memory usage: 8GB

CoreDNS:→ PriorityClass: system-cluster-critical (priority 2000000000)→ QoS: Burstable (request: 70Mi, no limit)→ Memory usage: 150Mi (spiked from 70Mi under DNS load)

kube-proxy:→ PriorityClass: system-node-critical (priority 2000001000)→ QoS: BestEffort (no config)→ Memory usage: 80Mi

But when memory spikes too fast for the Kubelet to react, the Linux Kernel OOM Killer takes over.

The Kernel doesn’t know about your PriorityClass. It only sees the QoS Class (via oom_score_adj).

By priority, your workload should die first.

And most of the time, it will.

But here’s the problem:

CoreDNS has NO memory limit.

With only a request (70Mi) and no limit, it can consume unlimited memory.

Under heavy DNS load (like when apps are failing and retrying), CoreDNS can spike to 150Mi, 200Mi, 300Mi.

That’s 2x, 3x, 4x its request.

What happens next:

Someone gets paged.

The fix that would have prevented this:

For CoreDNS (complete the partial config):

resources: requests: memory: 70Mi limits: memory: 170Mi # 2-3x for DNS spikes

For kube-proxy (add everything):

resources: requests: memory: 250Mi limits: memory: 250Mi

For your workload (proper configuration):

resources: requests: memory: 2Gi limits: memory: 4GipriorityClassName: low-priority-batch

Total: 12 lines of YAMLCost: $0Time to implement: 15 minutes

But most teams don’t do this.

Because “it’s working fine.”

Until it isn’t.

Everyone tells you: Set requests = limits for Guaranteed QoS.

That’s good advice for your applications.

But it’s incomplete.

You need TWO things:

Let me explain both.

QoS = Quality of Service

Kubernetes assigns every pod one of three QoS classes:

BestEffort:→ No requests or limits set→ Killed FIRST by the Kernel OOM Killer→ This is kube-proxy by default

Burstable:→ Request set, limit missing OR request < limit→ Killed SECOND by the Kernel OOM Killer→ This is CoreDNS by default

Guaranteed:→ Request = limit (for all resources)→ Killed LAST by the Kernel OOM Killer→ This is what you want for critical pods

The fix for different scenarios:

For pods with NO config (kube-proxy):

resources: requests: memory: 250Mi cpu: 100m limits: memory: 250Mi cpu: 100m

For pods with partial config (CoreDNS):

Current default:

resources: requests: memory: 70Mi cpu: 100m

Add limits:

resources: requests: memory: 70Mi cpu: 100m limits: memory: 170Mi # Allow 2-3x for DNS spikes cpu: 100m

This changes them from BestEffort/Burstable → Guaranteed.

But QoS alone isn’t enough.

Check your system pods:

kubectl get pods -n kube-system -o custom-columns=\NAME:.metadata.name,\PRIORITY:.spec.priorityClassName

You’ll see:

coredns-xxxxx: system-cluster-criticalkube-proxy-xxxxx: system-node-critical

These have Kubernetes system priority classes.

Check your app pods:

kubectl get pods -n <your-namespace> -o custom-columns=\ NAME:.metadata.name,\ PRIORITY:.spec.priorityClassName

Probably shows:

No PriorityClass = priority 0 (lowest).

The complete protection requires BOTH.

Create PriorityClasses for your applications:

apiVersion: scheduling.k8s.io/v1kind: PriorityClassmetadata: name: high-priority-appvalue: 1000000globalDefault: falsedescription: “High priority for critical application pods”

apiVersion: scheduling.k8s.io/v1kind: PriorityClassmetadata: name: medium-priority-appvalue: 100000globalDefault: falsedescription: “Standard priority for application pods”

apiVersion: scheduling.k8s.io/v1kind: PriorityClassmetadata: name: low-priority-batchvalue: 10000globalDefault: falsedescription: “Low priority for batch jobs”

Priority reference:

→ system-cluster-critical: 2000000000→ system-node-critical: 2000001000→ Your critical apps: 1000000→ Your standard apps: 100000→ Your batch jobs: 10000→ Default (no class): 0

Set them BELOW system pods but ABOVE default.

Then apply to your pods:

Critical apps:

spec:priorityClassName: high-priority-appcontainers:- name: app resources: requests: memory: 500Mi limits: memory: 500Mi

Batch jobs:

spec:priorityClassName: low-priority-batchcontainers:- name: batch resources: requests: memory: 1Gi limits: memory: 4Gi

Now the complete OOM/Eviction hierarchy:

Within each priority level:→ BestEffort killed before Burstable→ Burstable killed before Guaranteed

This is complete protection:

✅ Memory limits (QoS)✅ Priority hierarchy (PriorityClass)✅ System pods protected✅ Critical apps protected✅ Batch jobs sacrificed first

kubectl get pods --all-namespaces -o json | jq ‘.items[] | select(.spec.containers[].resources.requests.memory == null) | .metadata.name’

These are BestEffort QoS (most vulnerable).

kubectl get pods --all-namespaces -o custom-columns=\ NAME:.metadata.name,\ NAMESPACE:.metadata.namespace,\ PRIORITY:.spec.priorityClassName,\ QOS:.status.qosClass,\ MEM-REQ:.spec.containers[0].resources.requests.memory,\ MEM-LIM:.spec.containers[0].resources.limits.memory

Look for:❌ BestEffort + no priority = most vulnerable❌ Burstable + no priority = vulnerable❌ System pods with Burstable = incomplete config✅ Guaranteed + proper priority = protected

Priority order:

Start with pods where failure = platform failure:→ CoreDNS (DNS for entire cluster)→ kube-proxy (network routing)→ Your revenue-generating apps

Option A: Use Goldilocks (recommended)

Install: https://goldilocks.docs.fairwinds.com/installation/

Wait 24-48 hours for data collection.

Check dashboard for recommendations based on actual usage.

Option B: Manual calculation

kubectl top pods -n <namespace>

Take current usage.Add 30-50% buffer.Set request = limit for Guaranteed QoS.

Starting points:→ CoreDNS: 70Mi request → 170Mi limit→ kube-proxy: 250Mi (both)→ Your apps: Measure actual usage + buffer

For CoreDNS (add limit to existing config):

kubectl edit deployment coredns -n kube-system

Change:

resources: requests: memory: 70Mi

To:

resources: requests: memory: 70Mi limits: memory: 170Mi

For kube-proxy (add everything):

kubectl edit daemonset kube-proxy -n kube-system

Add:

resources: requests: memory: 250Mi cpu: 100m limits: memory: 250Mi cpu: 100m

For your apps (add memory + priority):

Create PriorityClasses first (see templates above).

Then update deployments:

spec: priorityClassName: high-priority-app containers: - name: app resources: requests: memory: 500Mi limits: memory: 500Mi

Check for:→ OOM kills:

kubectl get events --all-namespaces | grep -i oom

→ Pod restarts:

kubectl get pods --all-namespaces

→ Memory pressure:

kubectl describe nodes | grep -i pressure

→ QoS verification:

kubectl get pods -o custom-columns=NAME:.metadata.name,QOS:.status.qosClass

If a pod hits its limit and gets OOM killed:→ Increase limit by 25-50%→ OR investigate for memory leak

Don’t just raise limits without investigating why.

I found this in MY OWN practice cluster.

Not a client.Not a consulting engagement.My own infrastructure that I use to explore Goldilocks and K8s cost optimization.

And it has the same problems everyone’s clusters have:→ System pods ship incomplete (CoreDNS with request, no limit)→ System pods ship empty (kube-proxy with nothing)→ Nobody completes the configuration→ Everything works fine

Until memory pressure hits.

The fix takes 30-60 minutes:

System pods: 15-20 minutes (add limits)PriorityClasses: 10 minutes (create hierarchy)Application pods: 20-30 minutes (memory + priority)

One Saturday morning of work.

But most teams don’t do it.

Because there’s no incident yet.Because it’s “working fine.”Because nobody’s checking.

I’m checking.

And I’m sharing what I find.

Because 3 out of 4 system pods being vulnerable to OOM kill is not “working fine.”

It’s a time bomb.

Don’t wait for the 3am page.

See you next Tuesday- Naveen

P.S. - If this was useful, forward it to your DevOps team. They’ll thank you when they’re NOT explaining to management why CoreDNS died despite having system-cluster-critical priority, because nobody ever added the memory limit that Kubernetes doesn’t set by default.
